Kansas City ARTCC (1962-Active) - One of 22 Federal Aviation Administration (FAA) Air Route Traffic Control Centers (ARTCC)s in the United States. Established in 1962 near Olathe, Johnson County, Kansas. Assigned an FAA ID of ZKC. Active FAA Air Traffic Control Center. Also known as Kansas City Center.

Kansas City ARTCC

History

The original Kansas City Center was commissioned during World War II on 1 Feb 1942 and was located at the Kansas City Municipal Airport with 15 employees. Late in 1942, the Center was relocated to the 16th floor of the city hall in Kansas City, Missouri. On 30 Apr 1962, the Center moved to its current location at 250 S. Rogers Rd. Olathe, Kansas. The Kansas City Center covers a part of the FAA's Central service area.

Initially, the 20 ARTCCs in the lower 48 States were equipped with IBM 9020 computers to automate some of the ARTCC functions. In 1988 the IBM 3083 computer system known as "Host" replaced the old IBM 9020s in these ARTCCs. On 14 Jun 2012, the FAA decommissioned the 4-decades-old En Route Host computer system at the Seattle and Salt Lake City ARTCCs and replaced the system with the new En Route Automation Modernization (ERAM) system. As of 27 Mar 2015, all 20 of the lower 48 United States ARTCCs had converted to the ERAM system as had the FAA Academy in Oklahoma City, Oklahoma.

ERAM technology is the heart of the Next Generation Air Transportation System (NextGen) and the pulse of the National Airspace System (NAS), helping to advance the transition from a ground-based system of air traffic control to a satellite-based system of traffic management. ERAM can process data from 64 radars versus the 24 radar processing with the legacy HOST system.

Operation

The Federal Aviation Administration (FAA) system of 24 FAA Area Control Centers, 20 in the lower 48 United States, one in Alaska, one in Hawaii, one in Puerto Rica and one in Guam. The system operates with radar data provided by FAA radar sites, DoD radar sites, and other federal agency radar sites. These centers provide en route and oceanic services to private, commercial, and military aircraft overflying their respective control areas. As aircraft enter or exit from one control area to the next, responsibility for the aircraft is transferred to the gaining ARTCC. Voice communication between aircraft and the ARTCCs is supported by a network of ground-air radio sites often co-located with the radar sites.

The gathering of radar, beacon and other sensor data are now largely automated and continuous, but the actions necessary to control the airspace are conversational and require some 14,000 FAA air traffic controllers talking directly to pilots in the air and on the ground at terminals. This number does not include military air traffic controllers.

Kansas City ARTCC (ZKC)
Total Operations (aircraft handled) 1,751,235 FY2016
Total Operations (aircraft handled) 1,792,081 FY2017
Operations Rank 15/24 FY2017
En-Route Air Traffic Controllers 237 a/o 17 Sep 2016
Airspace Area (sq miles) 177,000


Kansas City ARTCC Controlled Radar Sites (edit list)
FAA JSS NORAD Site St_ Equip_ Status Origin GPS ARTCC Notes
ZSTL St. Louis MO CARSR
ATCBI-6
Active 38.70083,
-90.39056
ZKC
ZIRK Z-064 Kirksville MO CARSR
ATCBI-6
Active Kirksville AFS 40.29778,
-92.57556
ZKC
ZGCK Z-226 Z-226 Garden City KS CARSR
Mode S
Active 37.66417,
-100.87167
ZKC
ZHTI Z-047 Hutchinson KS CARSR
ATCBI-6
Active Hutchinson AFS 37.92611,
-97.88694
ZKC *
ZQBZ Oskaloosa KS CARSR
ATCBI-6
Active 39.22194,
-95.24611
ZKC

Note: This list includes only long-range FAA Radar Sites listed with this ARTCC as the Overlying Enroute Center. Adjacent ARTCC sector sites are not shown and short-range terminal radar sites are not shown.

Current Status

Active FAA facility in Olathe, Johnson County, Kansas.


Location: 250 S. Rogers Rd. Olathe, Kansas

Maps & Images

Lat: 38.88005 Long: -94.79063

  • Multi Maps from ACME
  • Maps from Bing
  • Maps from Google
  • Elevation: 1,069'


GPS Locations:

See Also:

Sources:

  • Kansas City ARTCC- Facility Guide
  • Administrator's Fact Book, Federal Aviation Administration, May 2019, archived 4 Jun 2019, Pdf
  • 2017-2026 Air Traffic Controller Workforce Plan, Federal Aviation Administration, 2017, archived 5 Jun 2019, Pdf
  • Air Traffic by the Numbers, Federal Aviation Administration, 2018, archived 5 Jun 2019, Pdf
  • Computer system to Improve air safety unveiled in LA, The Napa Valley Register (Napa, California), 11 Mar 1988, page 20, archived 7 Jul 2019.
