Joint Surveilance System (1983-Present) - A joint system of long range radar sites operated mainly by the Federal Aviation Administration (FAA) with data used by them, the United States Air Force (USAF) and other federal agencies.


See Also:

JSS Command Center, FYQ-93 and BCS-F Locations (edit list)
ROCC/SOCC/SAOC Location State Unit From To GPS Notes
Rome Griffiss AFB NY NEADS 1983 2006 43.21667,
-75.40583 		Now BCS-F System
McChord McChord AFB WA NWADS 1983 2006 47.12167,
-122.50389 		Now BCS-F System
Tyndall Tyndall AFB FL SEADS 1983 2006 30.07500,
-85.59417 		Closed
March March AFB CA SWADS 1984 1995 33.89482,
-117.25055 		Closed
Elmendorf Elmendorf AFB AK AKADS 1983 2006 61.24416,
-149.81139 		Now BCS-F System
Wheeler Wheeler AAF HI HIRAOC 1984 2006 21.48262,
-158.04582 		Now BCS-F System
CAN-East CFB North Bay ON CAN-East 1983 2005 46.3375,
-79.41167 		Now BCS-F System
CAN-West CFB North Bay ON CAN-West 1983 2005 46.3375,
-79.41167 		Now BCS-F System
ICE Keflavik NAS IS Iceland 1984 2006 63.96166,
-22.59166 		Closed
Official Map of Department of Defense (DoD) and Department of Homeland Security (DHS) Long Range Radar Sites. Excludes FPS-117 Sites.



FAA and JSS Radar Sites (edit list)
FAA JSS NORAD Site St_ Equip_ Status Origin GPS ARTCC Notes
QRB J-12 Z-336 Citronelle AL CARSR
ATCBI-6 		Active Replaced Dauphin Island different location 31.03987,
-88.23775 		ZHU *
QPC Haleyville AL CARSR
ATCBI-6 		Active 34.41556,
-87.53972 		ZME
MGM Montgomery AL CARSR
ATCBI-6 		Active 32.21167,
-86.16833 		ZTL *
QXR Z-237 Russellville AR CARSR
ATCBI-6 		Active 35.40278,
-92.99417 		ZME
TXK Z-091 Texarkana AR CARSR
ATCBI-6 		Active Texarkana AFS
Different Location 		33.35972,
-93.92278 		ZFW
PHX J-29 Z-247 Humboldt Mtn AZ CARSR
ATCBI-6 		Active 33.98139,
-111.79806 		ZAB Phoenix
QQO J-29A Ajo AZ ARSR-4
ATCBI-6M 		Active Ajo AFS 32.43111,
-112.94500 		ZAB Last ARSR-4 installation
QXP Seligman AZ CARSR
ATCBI-6 		Active 35.35278,
-112.94972 		ZLA
QSR Z-059 Boron CA CARSR
ATCBI-6 		Active Boron AFS 35.08226,
-117.58246 		ZLA *
CEC J-83 Z-033 Crescent City CA FPS-66A
Unk 		Closed-1995 Klamath AFS 41.55917,
-124.08611 		Gone
QZZ J-83A Rainbow Ridge CA ARSR-4
ATCBI-6M 		Active 40.39417,
-124.16611 		ZOA *
RBL Z-157 Red Bluff CA CARSR
Mode S 		Active Red Bluff AFS 40.14611,
-122.30444 		ZOA *
--- J-34 Z-037 Point Arena CA
Unk 		Closed-1995 Point Arena AFS 38.89306,
-123.54444 		Gone
QMV J-33 Z-038 Mill Valley CA ARSR-4
ATCBI-6M 		Active Mill Valley AFS 37.92389,
-122.59750 		ZOA *
PRB J-32 Z-236 Paso Robles CA ARSR-4
ATCBI-6M 		Active 35.39472,
-120.35417 		ZLA
QLA J-31 Z-039 San Pedro CA CARSR
ATCBI-6 		Active San Pedro AFS 33.74611,
-118.33611 		ZLA *
NSD J-36A San Clemente Island CA ARSR-4
Unk 		Active 32.88417,
-118.45083 		ZLA Navy JSS Site
QRW J-30 Z-076 Mount Laguna CA ARSR-4
ATCBI-6M 		Active Mount Laguna AFS 32.87611,
-116.41500 		ZLA *
XVBG J-35 Vandenberg AFB CA ARSR-4
Unk 		Active 34.58694,
-120.59472 		ZLA USAF only
QPK Z-212 Denver
(Parker) 		CO CARSR
Mode S 		Active 39.59417,
-104.69306 		ZDV *
GJT Z-215 Grand Junction CO CARSR
Mode S 		Active 39.63861,
-108.76250 		ZDV
TAD Z-222 Trinidad CO CARSR
Mode S 		Active 37.54694,
-104.01389 		ZDV *
NEN J-04 Z-327 Whitehouse
(Jacksonville) 		FL ARSR-4
ATCBI-6M 		Active 30.34583,
-81.87361 		ZJX
COF J-05 Z-211 Patrick AFB FL FPS-66A
Unk 		Closed-1996 Patrick AFB 28.21389,
-80.59917 		ZJX *Gone
MLB J-05A Melbourne FL ARSR-4
ATCBI-6M 		Active 28.08417,
-80.79806 		ZJX *
--- J-06 Z-210 Richmond FL ARSR-1E
Unk 		Closed 1992 Richmond AFS 25.62333,
-80.40445 		ZMA Gone
Hurricane Andrew
QM8 J-06A Tamiami FL ARSR-4
ATCBI-6M 		Active 25.64722,
-80.50528 		ZMA First ARSR-4 installation
NQX J-07 Z-209 Key West FL ARSR-4
ATCBI-6M 		Active 24.58444,
-81.68917 		ZMA Navy/FAA
QJT J-09 Z-330 Fort Lonesome FL ARSR-3
Unk 		Closed-1998 27.64556,
-82.13278 		ZMA Gone
FN7 J-09A Fort Green FL ARSR-4
ATCBI-6M 		Active 27.70056,
-82.00694 		ZMA
CTY J-10 Z-333 Cross City FL ARSR-4
ATCBI-6M 		Active 29.74389,
-83.00083 		ZJX
PAM J-11 Z-198 Tyndall AFB FL ARSR-4
ATCBI-6M 		Active 30.07583,
-85.61083 		ZJX Hurricane Michael (2018) destroyed radome and antenna
NOAA image. Restored to operation 16 Nov 2018.
--- J-08 Z-399 Cudjoe Key FL L-88(V)3
Unk 		24.70094,
-81.50610 		--- B-94
QHN Ashburn GA CARSR
ATCBI-6 		Active 31.69583,
-83.75028 		ZJX *
QNK Lincolnton GA CARSR
ATCBI-6 		Active 33.75972,
-82.46695 		ZTL *
ATL Z-111 Marietta
(Atlanta) 		GA CARSR
ATCBI-6 		Active Marietta AFS 33.89411,
-84.49876 		ZTL *
QJO Arlington IA CARSR
ATCBI-6 		Active 42.76833,
-91.61528 		ZAU *
QVA Z-225 Ashton ID CARSR
Mode S 		Active 44.56250,
-111.44472 		ZLC *
QCK Z-223 Cascade
(Boise) 		ID CARSR
Mode S 		Active 44.44250,
-116.13694 		ZLC
JOL Joliet
(Elwood) 		IL CARSR
ATCBI-6 		Active 41.42278,
-88.05833 		ZAU
QUZ Z-085 Hanna City IL CARSR
ATCBI-6 		Active Hanna City AFS 40.69889,
-89.82583 		ZAU
IND Indianapolis IN CARSR
ATCBI-6 		Active 39.74611,
-86.28472 		ZID
QTZ La Grange IN CARSR
ATCBI-6 		Active 41.63111,
-85.41472 		ZAU
GCK Z-226 Garden City KS CARSR
Mode S 		Active 37.66417,
-100.87167 		ZKC
HTI Z-047 Hutchinson KS CARSR
ATCBI-6 		Active Hutchinson AFS 37.92611,
-97.88694 		ZKC *
QBZ Oskaloosa KS CARSR
ATCBI-6 		Active 39.22194,
-95.24611 		ZKC *
QRI Z-232 Lynch KY CARSR
ATCBI-6 		Active 36.91611,
-82.89097 		ZID
AEX Alexandria LA CARSR
ATCBI-6 		Active England AFB 31.31435,
-92.53062 		ZHU *
--- J-14 Z-248 Lake Charles AFS LA
Unk 		Closed-1990s Lake Charles AFS 30.18472,
-93.17500 		Gone
LCH J-14A Lake Charles LA ARSR-4
ATCBI-6M 		Active 30.36056,
-93.51139 		ZHU *
NEW J-13 Z-246 Slidell LA ARSR-4
ATCBI-6M 		Active 30.34806,
-89.77944 		ZHU *
QHA Cummington MA CARSR
ATCBI-6 		Active 42.47472,
-72.96806 		ZBW
QEA J-53 Z-010 North Truro MA ARSR-4
ATCBI-6M 		Active North Truro AFS 42.03417,
-70.05417 		ZBW *
QYA J-54 Z-110 Bucks Harbor ME ARSR-4
ATCBI-6M 		Active Bucks Harbor AFS 44.62944,
-67.39528 		ZBW *Not on 2016 List
QYD J-63 Caribou ME ARSR-4
ATCBI-6M 		Active 46.88583,
-67.97139 		ZBW
CPV Coopersville MI CARSR
ATCBI-6 		Active 43.04556,
-85.99222 		ZAU
QJA J-58 Z-034 Empire MI ARSR-4
ATCBI-6M 		Active Empire AFS 44.80194,
-86.05139 		ZMP *
QDT J-62 Z-397 Canton MI CARSR
ATCBI-6 		Active 42.27667,
-83.47417 		ZOB
QJE Apple Valley MN CARSR
ATCBI-6 		Active 44.75250,
-93.22778 		ZMP
QJD J-60 Z-306 Nashwauk MN ARSR-4
ATCBI-6M 		Active 47.39750,
-93.17028 		ZMP
QJC Tyler MN CARSR
Mode S 		Active 44.19361,
-96.20417 		ZMP
STL St. Louis MO CARSR
ATCBI-6 		Active 38.70083,
-90.39056 		ZKC
IRK Z-064 Kirksville MO CARSR
ATCBI-6 		Active Kirksville AFS 40.29778,
-92.57556 		ZKC *
QYB Z-233 Byhalia
(Memphis) 		MS CARSR
ATCBI-6 		Active 34.85278,
-89.76583 		ZME *
QNM Newport MS CARSR
ATCBI-6 		Active 32.94750,
-89.84472 		ZME
--- J-77 Z-147 Malmstrom AFB FAA MT
Unk 		Closed-1996 Malmstrom AFB 47.50139,
-111.20306 		Gone
GTF J-77A Bootlegger Ridge MT ARSR-4
ATCBI-6M 		Active 47.61361,
-111.29028 		ZLC *
QLS J-78 Z-179 Lakeside MT ARSR-4
ATCBI-6M 		Active Kalispell AFS 48.01139,
-114.36500 		ZLC *
QRL Benson
(Raleigh) 		NC CARSR
ATCBI-6 		Active 35.51111,
-78.54889 		ZDC
QRM Maiden
(Charlotte) 		NC CARSR
ATCBI-6 		Active 35.61083,
-81.23833 		ZTL
QGV J-02 Z-115 Fort Fisher NC ARSR-4
ATCBI-6M 		Active Fort Fisher AFS 33.97722,
-77.91556 		ZDC
QFI J-75 Z-303 Finley ND ARSR-4
ATCBI-6M 		Active Finley AFS 47.52833,
-97.90083 		ZMP *
QWA J-76 Z-300 Watford City ND ARSR-4
ATCBI-6M 		Active 47.67889,
-103.78056 		ZMP
QHO Z-071 Omaha NE CARSR
ATCBI-6 		Active Omaha AFS 41.36028,
-96.02500 		ZMP *
LBF Z-217 North Platte NE CARSR
Mode S 		Active 40.83278,
-100.74806 		ZDV
QJM Rockville NE BOS
Mode S 		Active 41.14105,
-98.80511 		ZMP
QIE J-51 Z-063 Gibbsboro NJ ARSR-4
ATCBI-6M 		Active Gibbsboro AFS 39.82472,
-74.95417 		ZNY
QSA Z-094 West Mesa
(Albuquerque) 		NM CARSR
ATCBI-6 		Active West Mesa AFS 35.0717,
-106.86972 		ZAB *
GUP Z-221 Gallup NM CARSR
Mode S 		Active 36.07583,
-108.86028 		ZDV
QWC Z-234 Mesa Rica NM CARSR
Mode S 		Active 35.23751,
-104.20450 		ZAB
SVC J-28 Z-245 Silver City NM CARSR
ATCBI-6 		Active 32.98917,
-108.96056 		ZAB
DMN J-28A Deming NM ARSR-4
ATCBI-6M 		Active 32.49167,
-107.16639 		ZAB
BAM Z-214 Battle Mountain NV CARSR
ATCBI-6 		Active 40.40306,
-116.86778 		ZLC
NFL Z-156 Fallon NV CARSR
Mode S 		Active Fallon AFS 38.77444,
-118.02139 		ZOA *
QAS Z-163 Angel Peak NV CARSR
Mode S 		Active Las Vegas AFS 36.318611,
-115.57528 		ZLA *
TPH Z-164 Tonopah NV BOS
Mode S 		Active Tonopah AFS 38.05167,
-117.22556 		ZLC *Not on 2016 List
QVH J-52 Z-315 Riverhead NY ARSR-4
ATCBI-6M 		Active 40.87861,
-72.687222 		ZNY
QXU J-55 Z-312 Remsen
(Utica) 		NY ARSR-4
ATCBI-6M 		Active Replaced Watertown AFS 43.34528,
-75.248889 		ZBW *
DSV J-56 Z-309 Dansville NY CARSR
ATCBI-6 		Active 42.63833,
-77.652778 		ZNY
QDB Brecksville
(Cleveland) 		OH CARSR
ATCBI-6 		Active 41.30222,
-81.683611 		ZOB
QWO London OH CARSR
ATCBI-6 		Active 39.84611,
-83.48167 		ZID
OKC Oklahoma City OK CARSR
ATCBI-6 		Active 35.40306,
-97.62833 		ZFW *
QVN Fossil OR CARSR
ATCBI-6 		Active 44.96028,
-119.9517 		ZSE
LMT J-82 Z-180 Klamath Falls OR CARSR
ATCBI-6 		Active Keno AFS 42.06889,
-121.97222 		ZSE
QFL J-81 Z-345 Falls City OR ARSR-4
ATCBI-6M 		Active 44.92278,
-123.57361 		ZSE Changed from Salem (SLE), 2012
QRC Z-030 Benton PA CARSR
ATCBI-6 		Active Benton AFS 41.35738,
-76.29296 		ZNY
QCF Clearfield
(Du Bois) 		PA CARSR
ATCBI-6 		Active 41.07028,
-78.55028 		ZOB
PIT Z-062 Oakdale PA CARSR
ATCBI-6 		Active Oakdale AFS 40.39722,
-80.16111 		ZOB
QDP J-61 Trevose PA ARSR-60
Unk 		Closed
1998 		40.13417,
-74.98694 		ZNY Gone
QRJ J-03 Z-324 Jedburg SC ARSR-4
ATCBI-6M 		Active 33.06972,
-80.22056 		ZJX *
QJB Z-099 Gettysburg SD CARSR
Mode S 		Active Gettysburg AFS 45.05076,
-99.956156 		ZMP *
QOJ Z-235 Joelton
(Nashville) 		TN CARSR
ATCBI-6 		Active Joelton AFS 36.33611,
-86.86139 		ZME *
AMA Z-088 Amarillo TX CARSR
Mode S 		Active Amarillo AFB 35.24611,
-101.65694 		ZAB *
QYS Rogers TX CARSR
ATCBI-6 		Active 30.94389,
-97.26861 		ZHU *
ELP J-27 Z-244 El Paso TX ARSR-1E
Unk 		Closed-1997 31.68083,
-106.19722 		ZAB Gone
QNW J-27A Eagle Peak TX ARSR-4
ATCBI-6M 		Active 30.92028,
-105.08583 		ZAB
HOUA J-15 Z-240 Houston
Ellington 		TX CARSR
ATCBI-6 		Active Ellington AFB 29.61556,
-95.17306 		ZHU *
FTW Z-231 Keller TX CARSR
ATCBI-6 		Active 32.94444,
-97.22028 		ZFW *
SAT Z-241 Lackland TX FPS-66A
Unk 		Closed Lackland AFB 29.38803,
-98.63332 		ZHU *
QNA J-15A Morales TX ARSR-4
ATCBI-6M 		Active 29.34139,
-96.87167 		ZHU
QXS J-26 Z-243 Odessa TX CARSR
ATCBI-6 		Active 32.55417,
-102.42778 		ZFW
QOM J-26A King Mountain TX ARSR-4
ATCBI-6M 		Active 31.28500,
-102.27333 		ZAB *
QZA J-16 Z-242 Oilton TX ARSR-4
ATCBI-6M 		Active 27.49889,
-98.96944 		ZHU
SOA J-25 Z-339 Sonora TX ARSR-3
Unk 		Closed-1997 30.47111,
-100.55806 		ZHU Gone
RSG J-25A Rocksprings TX ARSR-4
ATCBI-6M 		Active 30.04667,
-100.26778 		ZHU
CDC Z-216 Cedar City UT CARSR
Mode S 		Active 37.59306,
-112.86361 		ZLC *
FPK Z-213 Francis Peak
(Salt Lake City) 		UT CARSR
Mode S 		Active 41.03278,
-111.83833 		ZLC *
QHB Z-014 Saint Albans VT CARSR
Mode S 		Active Saint Albans AFS 44.78167,
-73.06556 		ZBW
QBN Binns Hall VA CARSR
ATCBI-6 		Active 37.38278,
-76.99861 		ZDC
QVR J-01 Z-321 Oceana NAS VA ARSR-4
ATCBI-6M 		Active 36.82722,
-76.01361 		ZDC *FAA/USAF/Navy
QPL J-50 Z-318 The Plains VA CARSR
ATCBI-6 		Active 38.88250,
-77.70278 		ZDC
QBE Z-121 Bedford VA CARSR
ATCBI-6 		Active Bedford AFS 37.51722,
-79.51028 		ZDC *
SEA Z-001 Fort Lawton
(Seattle) 		WA CARSR
ATCBI-6 		Active Fort Lawton AFS 47.6575,
-122.41306 		ZSE *
QMI J-79 Z-151 Mica Peak WA ARSR-4
ATCBI-6M 		Active Mica Peak AFS 47.57389,
-117.08111 		ZSE *
QKW J-80 Z-044 Makah WA ARSR-4
ATCBI-6M 		Active Makah AFS 48.37167,
-124.67500 		ZSE *
QHZ Horicon WI CARSR
ATCBI-6 		Active 43.44583,
-88.49222 		ZAU
QSI Z-224 Lovell WY CARSR
Mode S 		Active 44.81694,
-107.90222 		ZLC *
LSK Z-219 Lusk WY CARSR
Mode S 		Active 42.59389,
-104.58833 		ZDV
RKS Z-218 Rock Springs WY CARSR
Mode S 		Active 41.43472,
-109.11750 		ZLC
ENA A-14 Kenai AK CARSR
ATCBI-6 		Active 60.61560,
-151.28313 		ZAN
BTI A-21 Barter Island AK FPS-117
Unk 		Active 70.13041,
-143.63938 		ZAN Not on 2016 List
LUR A-13 Cape Lisburne AK FPS-117
Unk 		Active Cape Lisburne AFS 68.87057,
-166.15039 		ZAN Not on 2016 List
EHM A-09 Cape Newenham AK FPS-117
Unk 		Active Cape Newenham AFS 58.62667,
-162.07611 		ZAN Not on 2016 List
CZF A-10 Cape Romanzof AK FPS-117
Unk 		Active Cape Romanzof AFS 61.78472,
-165.945833 		ZAN Not on 2016 List
CDB A-08 Cold Bay AK FPS-117
Unk 		Active 55.24528,
-162.77 		ZAN Not on 2016 List
FYU A-01 Fort Yukon AK FPS-117
Unk 		Active Fort Yukon AFS 66.56083,
-145.20944 		ZAN Not on 2016 List
AKN A-07 King Salmon AK FPS-117
Unk 		Active King Salmon AFS 58.69250,
-156.67028 		ZAN Not on 2016 List
OTZ A-12 Kotzebue AK FPS-117
Unk 		Active Kotzebue AFS 66.84333,
-162.59556 		ZAN Not on 2016 List
MPY A-02 Murphy Dome AK FPS-117
Unk 		Active Murphy Dome AFS 64.95194,
-148.35681 		ZAN Not on 2016 List
OLI A-19 Oliktok AK FPS-117
Unk 		Active Oliktok AFS 70.49833,
-149.88944 		ZAN Not on 2016 List
BRW A-17 Point Barrow AK FPS-117
Unk 		Active Point Barrow AFS 71.32722,
-156.63611 		ZAN Not on 2016 List
PIZ A-15 Point Lay AK FPS-117
Unk 		Closed 69.73556,
-163.01639 		ZAN Not on 2016 List
SVW A-06 Sparrevohn AK FPS-117
Unk 		Active Sparrevohn AFS 61.119167,
-155.59639 		ZAN Not on 2016 List
TLJ A-05 Tatalina AK FPS-117
Unk 		Active Tatalina AFS 62.92917,
-156.01417 		ZAN Not on 2016 List
TNC A-11 Tin City AK FPS-117
Unk 		Active Tin City AFS 65.57556,
-168.01056 		ZAN Not on 2016 List
UTO A-03 Indian Mountain AK FPS-117
Unk 		Active Indian Mountain AFS 66.06889,
-153.68625 		ZAN Not on 2016 List
QKK H-02 Mount Kokee HI FPS-117
Unk 		Active Kokee AFS 22.14778,
-159.645 		ZHN Not on 2016 List
QKA H-01 Mount Kaala HI ARSR-4
ATCBI-6M 		Active Kaala AFS 21.50750,
-158.14208 		ZHN
NAW Guantanamo Bay CU ARSR-4
Unk 		Active 19.900000,
-75.159444 		ZMA
Retrieved from "https://fortwiki.com/index.php?title=JSS_System&oldid=139889"
